Field Broadcast & Production SDI Video Rugged LCD Touchscreen Monitors By Xenarc Technologies

Field Broadcast & Production SDI Video Rugged LCD Touchscreen Monitors By Xenarc Technologies

Need a True Rugged, Tough and Reliable Field Production & Broadcast Monitors? #ProductionMonitors #BroadcastLCDs

Xenarc Technologies is the leading manufacturer of 12" SDI Touchscreen Display Monitors built tough and rugged for both indoor and outdoors.

Field Broadcast & Production SDI Video Rugged LCD Touchscreen Monitors By Xenarc Technologies

♦SDI & HDMI Video Input and SDI & HDMI Video Output

♦Waterproof Speakers

♦Sunlight Readable 1000NIT High Bright Perfect for Outdoors

♦IP67 Waterproof Tested & Certified

♦Built with Industrial Components

♦Withstands the harshest of environments both indoors and outdoors

♦Wide Viewing Angle IPS (In-Plane Switching) LCD Panel

♦Automatic Backlight Adjustment through Built-in Ambient Light Sensor

♦Projected Capacitive Multi-Touch Touchscreen (USB)

♦Optical Bonding, Anti-Reflective and Anti-Fingerprint Coating

♦Plug-N-Play with Windows 7 and up and Android devices (Downloadable drivers for other OS)

♦Multi-Monitor Touchscreen Support

♦ Vibration: Operating Random Vibration Test (5-500Hz, 1.0Grms), IEC 60068-2-64 standard

♦ Shock: Operating Shock Test, 10G peak acceleration (11ms duration), IEC 60068-2-27 standard

♦ MTBF (Mean Time Between Failures): > 55,000 Hours

♦Dimension (mm): 312W x 230H x 44.2D

♦ Weight (lb): 6.25

♦ 2 Year Warranty No Dead Pixel Guarantee

Field Broadcast & Production SDI Video Rugged LCD Touchscreen Monitors By Xenarc Technologies

BUY YOURS NOW:

https://www.xenarc.com/1219GNS-12.1-inch-sunlight-readable-IP67-IK08-optically-bonded-capacitive-touchscreen-with-SDI-HDMI-DVI-VGA-AV-Inputs-hdmi-sdi-video-output.html

#BroadcastMonitors #BroadcastLCDs #BroadcastDisplays#ProductionMonitors #ProductionLCDs #ProductionTouchscreens

#Iiot #industry40 #Automotive #CarDisplay #Car #telematics #SDI #HDMI#VGA #DVI #AV #VideoInput #VideoOutput #lcddisplay #lcdscreen #rugged#industrialautomation #iotsolutions #xenarc #medicaldisplays#industrialdisplays #militarydisplays #hmi #usb #digital #led #lcd #capacitive #ruggedness #outdoordisplays #trulyrugged

#Portable #Touchscreen #Monitor #SmallFormFactor #Manufacturing #LCD #LED #Display #Rugged #HeavyDuty #Industiral #Automotive

12.1" IP67 Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Industrial Display Monitor with SDI, HDMI, DVI, VGA & AV Inputs

Description

The Xenarc 1219 series 12.1” advanced touchscreen display is perhaps the most versatile and all-encompassing 12.1" display in Xenarc Technologies’ line up of products.  This 16:9 1000 NIT HMI (Human Machine Interface) screen is IP67 and IK08 rated and includes an optically bonded capacitive touchscreen, making it ideal for any harsh rugged industrial environment.  The touch panel is optically bonded to the LCD panel, eliminating the air gap between the two, increasing clarity, contrast, and durability.

Further, because the unit is water tight and air tight, ambient humidity will not affect the clarity or viewability because of the optical bonding.  The 1219GNS outperforms all automotive grade panels with a wider operating temperature range of -30C ~ 85C (-22F ~ 185F) and uses an IPS panel (In-Plane-Switching), which provides a wider viewing angle, consistent and accurate colors from all viewing angles, clearer images, and stable response times.  A high contrast ratio of 1000:1 provides crisper images and vivid colors, even in direct sunlight.

12.1" IP67 Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Industrial Display Monitor with SDI, HDMI, DVI, VGA & AV Inputs

The versatility of the 1219 12.1 inch capacitive touchscreen series extends beyond its usability in many different environments.  The 1219GNS can video interface through our proprietary 26 pin cable (HDMI, VGA, AV Inputs) as well as SDI and HDMI direct into the monitor.  HDMI output and SDI output allow you to chain up a few 1219 series monitors or output to other HDMI or SDI monitors.  With the included waterproof cables, the 1219GNS is IP67 on all sides.  The casing of the 1219GNS is designed to be used as a stand-alone monitor as well as a panel mount monitor.  VESA standard mounting holes on the back further provide users with numerous mounting options.  The IK08 ratingmakes the 1219GNS vandal resistant and shock resistant.

12.1" IP67 Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Industrial Display Monitor with SDI, HDMI, DVI, VGA & AV Inputs

The 1219GNS was designed for those looking for a true tested and certified rugged, bright, compact display, usable in just about any environment or application.  For the version without SDI input, please check out the 1219GNH.

Why do our products outlast others in extreme conditions? Why do our products have a wider temperature range and a wider voltage input range? It is because our mission is to offer our customers the best products for any situation. By utilizing high grade components, this display is perfect for industrial, in-car computing applications or any other applications where a small, durable, environmentally rugged display is required, including but not limited to:

• Transportation - Marine, Air, Heavy Vehicles, Mining, Weigh Stations, Fleet Management, Telematics, In-Car Computing, Public Transit, Cargo
• System Integration - Machinery Controls, Factory Automation, Environmental Monitoring, Home Automation, Military, Smart Home
• Point of Sale - Hospitality, Digital Signage, Self-Service Kiosks, Outdoor Kiosks and Signage, Casino
• Data Monitoring - Cloud, IoT, Medical, Logistics, Inventory Management, Oil & Gas/Utilities, Law Enforcement, Broadcasting, Veterinary, First Person View
• Broadcast & Production - Broadcast Stations, Mobile Production Vehicles, Field Rugged Deployment for your mobile workforce, Studio Video Production

12.1" IP67 Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Industrial Display Monitor with SDI, HDMI, DVI, VGA & AV Inputs

Features

• IP67 / NEMA6P Rated Water and Dust Resistance
• 1,000NIT Sunlight Readable with Long Life LED Backlight
• Wide Viewing Angle IPS (In-Plane Switching) LCD Panel
• Automatic Backlight Adjustment through Built-in Ambient Light Sensor
• Projected Capacitive Multi-Touch Touchscreen (USB)
• Optical Bonding, Anti-Reflective and Anti-Fingerprint Coating
• Plug-N-Play with Windows 7 and up and Android devices (Downloadable drivers for other OS)
• Multi-Monitor Touchscreen Support
• SDI Input x 1, HDMI Input x 1 (HDCP), VGA Input (15 pin D-SUB) x 1 & Video Input x 2
• SDI Output x 1, HDMI Output x 1, Analog Audio Output x 1
• Audio Input x 4 / Built-In Waterproof Speaker
• 1280x800 Native Resolution, 16x9 Aspect Ratio
• Chip Monolithic Ceramic Capacitors for Improved Durability
• High Performance Image and Video Signal Processor
• AISS - Advanced Image-Scaling and Shaping
• Last Input and Power Setting Memory
• IR Remote Control
• Auto Power-On upon signal detection
• Vertical Image Flip
• Function to Disable Front Button(s) and On Screen Text
• AV2 Auto Switching for Backup Camera
• VESA 75mm Mounting Holes
• 26-Pin Heavy-Duty Connector with Connector Locking
• Ruggedized Aluminum Casing
• Supports 9V DC ~ 36V DC
• "E" Mark Certified for Automotive use
• FCC, CE, E13 Certification
• IK08 Impact Resistant
• ROHS Compliant
• 24 Month Warranty
• 30 Day No dead Pixel Guarantee

12.1" IP67 Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Industrial Display Monitor with SDI, HDMI, DVI, VGA & AV Inputs

12.1" IP67 Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Industrial Display Monitor with SDI, HDMI, DVI, VGA & AV Inputs

12.1" IP67 Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Industrial Display Monitor with SDI, HDMI, DVI, VGA & AV Inputs

12.1" IP67 Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Industrial Display Monitor with SDI, HDMI, DVI, VGA & AV Inputs

12.1" IP67 Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Industrial Display Monitor with SDI, HDMI, DVI, VGA & AV Inputs
